Industrial door motor

Availability:
Quantity:

Master well's industrial door motor provides you with an integrated door system when you need it most to ensure your reliable performance. In consideration of convenience, our industrial door motor is safer to use and easier to perform daily work duties, so you can improve efficiency.

Summary

With stable performance and safety

Nice design, small volume

Low noise, long use life, no pollution

Low maintenance and no rusting

lEfficient team and superb workmanship

lConsiderable after-sales service

lVery competitive price

Application

It is widely used in buildings, garages, shopping malls, hotels, factories, warehouses, wharves, airports and other places.

Features

unique brake is provided for accurately stop the door.

In the event of power failure, the release device makes it possible to open and close the door manually.

Thermal protection.

Protection class: IP54.

Excellent sub-zero grease ensures quiet and stable operation, suitable for cold area.

Mechanical & electrical integration.

Wiring terminals for remote control, push button, pressure sensor and infrared photocell.

Parameters

Model

MO.SIF30

MO.SIF50

Power supply

220×(1±10%)V 50Hz

380×(1±10%)V 50Hz

Output torque

30 N.m

50 N.m

Output rotate speed

32 rpm

32 rpm

Motor rotate speed

1400 rpm

1400 rpm

Motor power

300 W

400 W

Thermal protection

120ºC

120ºC

Duty cycle

10min

20min

Ambient temperature

-20ºC ~+45ºC

-20ºC ~+45ºC

Barrel diameter

Ø25.4 mm

Ø25.4 mm

Flat key

6 x 5 x 70mm

6 x 5 x 70mm

Net weight

12 kg

12 kg

Dimensions

100 x 233 x 360

100 x 233 x 360

Max. rotation

28 cycles

28 cycles

Application Door SQM

<18 m²

<25 m²
