Single Sectional Garage Door

  • Model: Orange Peel only
  • Standard: Standard Double Track
  • Origin: Wuxi, China
  • Packing: Less than one container, wood cases is needed; Full container, carton box only.
  • TransTime: With 15-20 working days
  • Transportation: 1
  • Payment: T/T
Quantity:

Detailed Product Description: Single Sectional Garage Door

SF40S

Finger Protection Panel SF40S

1) Material: galvanized steel with PU foaming inside

2) Panel thickness: 40mm

3) Standard steel thickness: 0.35mm
4) Other available steel thickness: 0.4mm, 0.45mm, 0.5mm

5) Construction: Steel-foaming-steel sandwich construction, thriple layers

6) Front Design: wood grain only; wood grain with rectangle; wood grain with stripes; orange peel only, orange peel with rectangle; orange peel with stripes; flush with rectangle and reinforcing line; fold only; flush only

7) Surface finishes: wood grain, orange peel, flush with no grain

8) Max length: 12000mm

9) Panel width: 430mm-550mm, adjusted

10) Panel property: heat preservation, heat protection, dust protect

11) Standard color: Off white RAL9016

12) Available Solid colors: Brown RAL8014, Anthracite grey RAL7016, Silver RAL9006, Light beige RAL1019, Ebony RAL9004, Red RAL3000, Blue RAL5015

13) Available Timber colors: Mahogany, Gold oak, Walnut, Dark oak



Electrical Garage Door accessories:
1) Torsion spring, Hinges, Cable drum with cable, Central bracket with bearing, 1'' tube shaft, Mounting brackets and other accessories for a complete set
2) Standard Single Track (SST): 1 pair vertical track, 1 pair horizontal track, needs min headroom 350mm;
3) Standard Double Track (SDT): 1 pair vertical track, 1 pair horizontal track, 1 pair LHR horizontal track, needs min headroom 150mm;
4) L Profile support with Single Track (LST): 1 pair vertical track, 1 pair horizontal track with L profile support, needs min headroom 350mm;
5) L Profile support with Double Track (LDT): 1 pair vertical track, 1 pair horizontal track, a pair LHR horizontal track, with L profile support, needs min headroom 200mm
6) L Profile support with Double Track & ABS curve (SLDT) : 1 pair vertical track, 1 pair horizontal track, a pair LHR horizontal track, L profile with ABS curve, needs min headroom 200mm
GGD_06



Electrical Garage Door Opener

1) Rolling code / Digital limit switch

2) Input power: AC220V, 50HZ/ AC110V, 60HZ

3) Motor power: DC 24V

4) Radio frequency: 433.92MHz

5) Output torque: 8N.M, 10N.M, 12N.M, 15N.M

6) Max lifting height: 3.6m

7) Working environment: -20°C to +70°C

8) Protection class: IP20

9) Standard equipment: 2 transmitters, steel guide and other mounting brackets

10) Options: Wired / Wireless wall switch, Photocell, Wireless pin code lock, Back-up battery
Garage Motor1

Options

Master Well Workshop:

GGD_03


Packing Process and Container Loading: Electrical Garage DoorGGD_04

Customers Feedback:

We achieved win-win in business, we are also friends.

                                                                                                                   --Mr Sam Leo-Andoh

MASTER can offer a wide variety of garage doors for homes and businesses. Their doors make our company perfect solution to our customers.

                                                                                                                   ---Mr Adam Seipl

They are reliable business partner. Garage doors from MASTER add a functional and distinctive appearance to our business.

                                                                                                                   --- Mr. Arbi Sofian

I visited their factory and checked their garage doors. They are very professional. I placed my order to them.

                                                                                                                   ---Edward Grullon

 Choose us, not only your suppliers but also your good friends!
