Inflatable Loading Dock Shelter / Loading Dock Seal For Warehouse

Master Well inflatable dock seal can effectively compensate for the inconvenience caused by truck height difference and keep high tightness.
Color:customized
Size:customized
Material:PVC
Sales models:wholesale or retail
Min order:1 sets.
  • Inflatable

  • MasterWell

Availability:
Quantity:

Overview


Inflatable Dock Seal

Master Well inflatable dock seal is designed for the cold storage with large energy consumption and the loading and unloading environment with high air tightness requirements. It can closely fit with the truck carriage to achieve the function of complete isolation between the external gas and the internal.


充气门封 (4)


  • Power supply: 380V/50HZ

  • Power: 0.75kw

  • Protection Class: IP54

  • Control unit: Outside

  • Thickness: 3mm

  • Panel thickness: 50mm

  • Airbag thickness : 0.5mm

  • Airbag average time: 30s

  • Unit weight: 3.6kg/m

  • Material: Cordura 1000

  • The largest tensile ability: >290N/mm2

  • Working temperature: -35℃ - +70℃


Cases

seal1  seal2

seal 3  seal 4
